Submersible sewage pump - ASP
Vertical submersible sewage pump Wet/dry – cooling jacket from 11 kw up to 630 kw – IP68
Pump type : ASP
MATERIAL:
Motor Body Ductile Iron GGG 40/50
Cooling Jacket ST37-2 / AISI 304
Motor Shaft Is AISI 420 X20Cr13
Impeller Is Ductile Iron GGG/40/50
Motor Insulation Class H
1,3- 7,5 Kw Cooling Vane (Cooling Jacket Is Optional)
11-630 Kw Closed Circuit Cooling System
Discharge Outlets DN50-800
Protection Class: IP68
Type Of Starting: Star Delta, Directly, Soft Starter
IMPELLER TYPES:
Closed Impeller
One – Two – Three Channel Big Solid Size Impeller
One Channel Two Channel Contrablock (CB)
Open Impeller
Vortex Impeller
